Summary
- Define the specification of the bolt.
How to Run
- Ribbon Menu > [Model] Tab > [Component] Group > Bolt > Define
Explanation
Define a New Bolt Standard
Define a new bolt with a new standard.
[Select Bolt]
New : Define a new bolt with a new standard.
Existing Bolts : Modify the standard of previously defined bolts.
[Classification]
View or edit the classification properties of a bolt standard.
ID : Unique Number
Name : Name
Bolt Type : Bolt Type
Material : Material
[Bolt Shape]
Select and enter the dimensions of the bolt, nut and washer.
Modify and Existing Bolt Standard
Modifies a previously defined bolt standard.
[Select Bolt]
New : Define a new bolt with a new standard.
Existing Bolts : Modify the standard of previously defined bolts.
[Classification]
View or edit the classification properties of a bolt standard.
ID : Unique Number
Name : Name
Bolt Type : Bolt Type
Material : Material
[Bolt Shape]
Modify the dimensions of the bolt, nut and washer.
