Summary
- Create a 3D object by applying Fillet and Chamfer to the Plane object created in User Section Mode.
How to Run
[All Mode]
- Ribbon Menu > [Base] Tab > [Property] Group > User Section > Haunch
Explanation
Fillet Feature
This function applies fillets to the vertex of the selected object.
[Type]
Fillet : Use the Fillet feature.
Chamfer : Use the Chamfer feature.
[Fileter Radius]
Enter the length of the arc radius for the fillet.
[Pick Target]
Select the location for the fillet.
[Option]
Edge : Select two edges to create a fillet shape.
Vertext : Select one vertex to create a fillet shape.
Chamfer Feature
This feature applies chamfers to the vertex of the selected object.
[Type]
Fillet : Use the Fillet feature.
Chamfer : Use the Chamfer feature.
[Chamfer Length]
Enter the length of the chamfer to apply. The length entered for Length 1 is applied to Edge 1, and the length entered for Length 2 is applied to Edge 2.
[Pick Target]
Select two consecutive edges to select the target point.
[Option]
Edge : Select two edges to create a fillet shape.
Vertext : Select one vertex to create a fillet shape.
Haunch's Modify environment
This feature allows you to edit Haunch information in the Worktree > Data tab.
[Composition of Wotktree]
You can check Haunch's items in the Worktree > Data tab in User Section Mode.
(It is displayed in the Worktree only when Haunch is created.)
[Preview]
If you hover your mouse over the Haunch item in the Worktree > Data tab, the created haunch will be labeled as a label, allowing you to easily find the location of the Haunch.
[Modify]
If you right-click on the Haunch item in the Worktree > Data tab and select Modify, you will be taken to the edit screen.
Haunch Property
[Classification]
Name : Change the name of Haunch.
[Object Type]
Fillet / Champer : Information on the initially created Haunch is displayed, and the Haunch Type can be changed if necessary.
[Parameter]
You can match information defined in the parameter table.
