UCS

Summary

• Sets a user coordinate system that does not follow the global coordinate system.

How to Run

• Ribbon Menu > [Model] Tab > [Tools] Group > UCS

Explanation

UCS Coordinate Settings

Define the user coordinate system (UCS).

[Classification]

Set the ID and name of the UCS coordinate system.

[Coordinate System]

Use 3 points method to set the USC coordinate system.

Reference point : select the origin of the UCS coordinate system. Once selected, the coordinates of the origin are displayed.

X-axis : select a point in the x direction of the UCS coordinate system. Once selected, a vector in the x-direction is displayed.

Y-axis : select a point in the y direction of the UCS coordinate system. Once selected, a vector in the y-direction is displayed.
