Summar
- Enter Draw Diaphragm Mode to draw the diaphragm and stiffeners on the plane of the Closed Stiffener.
How to Run
- Ribbon Menu > [Model] Tab > [Component] Group > Stiffener > Draw Diaphragm
Explanation
Enter Draw Diaphragm Mode
Select the Closed Stiffener to enter Draw Diaphragm Mode.
[Select Target Member]
Select the Closed Stiffener object where the diaphragm, manhole, and stiffener reinforcements will be placed.
[Target Option]
Select the type of object to place the reinforcements on.
Detailed explanation (Target Option)
Create from Original Object
: Creates the plane based on the original object of the target member and enters Draw Mode. The reinforcements will be created on the original object of the target member.
Create from Result Object
: Create a plane for the result object of the target member to enter Draw Mode, and the reinforcement is created on the target member's application object.
[View Range]
Define the front and rear visibility range of the defined Draw Plane.
