1. Description
This component operates the Traffic Surface Lanes - Optimization function in Gen/Civil NX.
Moving load optimization allows you to find the number of loaded lanes and the exact position of vehicles in the transverse direction as well as longitudinal direction, which will give the most critical responses.
The Traffic Surface Lanes - Optimization function can be found in the Gen NX / CIVIL NX main menu, select [Load] tab > [Moving Load] tab > [Traffic Surface Lanes] tab > [Traffic Surface Lanes - Optimization]
2. Grasshopper Path
[Midas] > [Moving Load] > [Traffic Surface Lane - Optimization]
3. Component Image
4. Input/Output Value
- Input Data
| Index | Name | Description | Type | Default |
Previous Component |
|---|---|---|---|---|---|
| 1 | Name of Surface Lane | Name of Surface Lane | String | - | - |
| 2 | Optimization Lane | Optimization Lane | Real | - | - |
| 3 | Lane Width | Lane Width | Real | - | - |
| 4 | Divide Number | Number of Lanes | Real | - | - |
| 5 | Wheel Spacing | Wheel Spacing | Real | - | - |
| 6 | Margin | Margin | Real | - | - |
| 7 | Skew Start | Skew Start | Real | - | - |
| 8 | Skew End | Skew End | Real | - | - |
| 9 | Lane Items | Define Lane Items | Object | - | - |
- Output Data
| Index | Command | Description | Type | Method | Next Component |
|---|---|---|---|---|---|
| 1 | SLANop | Create Traffic Surface Lanes - Optimization | Json | PUT/DELETE | - |
5. Reference API Manual Link
Traffic Surface Lanes - Moving Load Optimization
